Diamondback Haanjo 8C

Diamondback Haanjo 8C


Regular price $3,499.99 USD
Regular price $4,599.99 USD Sale price $3,499.99 USD
Sale Sold out
In stock and ready to ship from our warehouse.

**Complete Bikes and overweight products will incur addtional shipping charges. We will contact you with an accurate estimate.**


The newest edition to the Haanjo family lightens the load

Meet the newest member of the Haanjo family. The Haanjo 8C is our first all carbon adventure bike. Utilizing the fan favorite DB carbon frame with endurance geometry, this bike continues in the Haanjo tradition of rugged comfort, with a relaxed headtube angle and carbon fork. This time around, we've added Easton EC70AX carbon wheels, as well as carbon handlebars and seatpost, making the ride even lighter while keeping the stability of WTB Riddler 700x37c tires. A Shimano GRX drivetrain keeps shifting smooth with gears that work with you to conquer pavement, gravel, and dirt. If you're looking for a top-of-the-line performance bike that can do-it-all including keeping you comfortable, the Haanjo 8C is your new go-to.

- Handmade carbon frame w/ Endurance Geometry and 12mm thru-axle rear is lightweight, rugged and comfortable
- DB Gravel Full Monocoque Carbon Disc fork, 12mm thru-axle
- Shimano GRX810 2x11 drivetrain components provide years of precise, reliable shifting
- Shimano hydraulic disc brakes provide peerless power and control
- Easton EC70AX carbon wheels are light and fast but durable for the off road rides


Frame DB Carbon Alternative Road Frame, Endurance Geometry, Relaxed Headtube Angle, Disc Specific, w/ 142x12 Thru-axle, Replaceable Hanger
Fork DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube
Headset FSA No.42, Sealed Cartridge
Axles Front: 100 x 12mm thru axle
Rear: 142 x 12mm thru axle
Rims/Wheels Easton EC70AX, Carbon, 28h, 24mm Internal Width, Tubeless Ready
Hubs Front: Easton EC70AX, 28h Aluminum Sealed Cartridge, Center Lock, 12mm Thru Axle
Rear: Easton EC70AX, 28h Aluminum Sealed Cartidge, Center Lock, 12mm Thru Axle
Spokes Sapim Double Butted, 2.0/1.8/2.0
Tires WTB Riddler, Dual DNA Compound, Lightweight Casing Tubeless, 700x37c
Crankset Praxxis Girder, Direct Mount
Chainrings 48/32T
Bottom Bracket Praxxis M30 Sealed
Chain KMC X11EL, 11 Speed
Front Derailleur Shimano GRX810, 31.8mm Band Clamp
Rear Derailleur Shimano GRX810, Shadow Plus, 11 Speed
Cassette/Rear Cogs Shimano CS-HG800 Cassette, 11 Speed, 11-34T
Shifters Shimano GRX810 Dual Control 2x11 Speed
Handlebars Easton EC70AX, Carbon, 16 Degree Flare, 31.8mm Bar Bore
Tape/Grips Diamondback Endurance Gel Tape
Stem Easton EA70, +/-7° Rise, 31.8 Bar Bore
Brake Levers Shimano GRX810
Brakes Shimano BR-RX810 Flat Mount Hydraulic Disc, w/160mm Front / 160mm Rear, RT800 Rotors
Saddle WTB Silverado Pro
Seat Post Easton EC70, Carbon 27.2
Accessories & Extras Tool Kit, Tubeless Valves, Chainstay Protector, Carbon Paste
